MC-DRT3.5HXXP-K-0001
MC-DRT3.5HXXP-K-0001
3.5mm，160V，8A
CE,UL
| 產品型號 SUPU ID |
MC-DPT3.5VXX-F-BK-2000 | ||
| 產品間距 Pitch |
3.5mm | ||
| 產品層數 Number of levels |
2 | ||
| 產品位數 Number of connections |
2P-18P | ||
| 接線方式 Connection method |
- | ||
| 防護等級 Protection Level |
IP20 | ||
| 工作溫度 Work temperature |
-40~+105℃ | ||
| 額定電流 Rated Current |
8A | ||
| 額定電壓 Rated Voltage |
160V | ||
| 過壓類別 Overvoltage category |
Ⅲ | Ⅲ | Ⅱ |
| 污染等級 Pollution degree |
3 | 2 | 2 |
| 額定沖擊電壓 Rated impulse voltage |
2.5KV | 2.5KV | 2.5KV |
| 額定電壓 Rated Voltage |
160V | 160V | 250V |
| 硬導線截面積 Conductor cross section solid |
- | ||
| 柔性導線截面積 Conductor cross section flexible |
- | ||
| 柔性導線截面積，帶絕緣管套 Conductor cross section flexible,with furrule |
- | ||
| 鎖線螺釘規格 Locking screw Specification |
- | ||
| 額定扭矩 Rated Torque |
- | ||
| 固定螺釘規格 Fixed Screw Specification |
M2.0 | ||
| 額定扭矩 Rated Torque |
0.2-0.25N.m | ||
| 剝線長度 Stripping length |
- |
| 使用組別 Use group |
B |
C |
D |
| 額定電流 Rated Current |
8A |
8A | - |
| 額定電壓 Rated Voltage |
150V |
50V | - |
| 額定接線容量 Rated cross section |
- |
| 絕緣材料 Insulation material |
LCP |
| 絕緣材料組別 Insulation material group |
Ⅲa |
| 阻燃等級，符合UL94 Flame retardant grade, UL94 compliance |
V0 |
| 導電體材料 Contact material |
Copper alloy |
| 導電體表面鍍層 Surface characteristics |
Sn,Plated |
| 認證圖標 Certificate |
 |
||
| UL證書號 UL file No. |
|||
| VDE證書號 VDE No. |
|||
| TUV證書號 TUV No. |
|||
